API 16C Monogrammed Choke & Kill Hoses
API 16C Monogrammed Choke & Kill Hoses
$0.00
Regular Choke & Kill Hose
SPEC 090-1915C
10,000 PSI Working Pressure
___
Master Choke & Kill Hose
SPEC 090-1910C
Hose and coupling are suitable for H2S service. Couplings are Ni-Kanigen plated for salt water resistance.
Application:
Choke & Kill Suitable for H2S
Working Temperature -20F to 212F
Max Length: 200 ft.
Choke & Kill Hose
API 16C LICENSED, CERTIFICATE No API-0383 FSL3
Non API16 C Monogramed 4" 10,000 Working Pressure and 2" Through 3" 15,000PSI Working Pressure Choke & Kill Hoses Available
| ID (inches) | OD (inches) | MBR (inches) | Straight Ends (inches) | Working Pressure (PSI) | Test Pressure (PSI) | Armored Weight (lbs/ft) | Unarmored Weight (lbs/ft) | Coupling Weight (lbs) |
| 2 | 4.3 | 36 | 40 | 5,000 | 10,000 | 20 | 16 | 65 |
| 4.5 | 36 | 42 | 10,000 | 15,000 | 22 | 16 | 104 | |
| 2.5 | 5.0 | 36 | 42 | 10,000 | 15,000 | 36 | 28 | 100 |
| 3 | 5.7 | 36 | 40 | 5,000 | 10,000 | 25 | 20 | 81 |
| 6.3 | 36 | 42 | 10,000 | 15,000 | 35 | 31 | 110 |
